De Facto Standard for New Era
| Hot and Ambient Model | |
|---|---|
 |
Test Site: Max 32 Site Test Pitch: 32site (30x60mm/40x60mm) 16site (30x60mm/40x60mm) 8site (40x60mm/60x60mm/80x60mm) 4site (80x60mm) Index Time: Min 0.4 sec UPH: Max 13,200 Temperature: 50 to 150 deg C +50 to 90 deg C: +/- 2 deg C +90 to 125 deg C: +/- 3 deg C +125 to 150 deg C: +/- 5 deg C Contact Forece: 120 kgf (240/480 kgf with High Contact Forece Option) |
 |
Test Site: 4 site (8 site as option) Test Pitch: 8site (40x60mm/60x60mm), 4site (80x60mm) Index Time: Min 0.39 sec UPH: Max 8,300 Temperature: +50 to 90 deg C +/- 2 deg C, +90 to 130 deg C +/- 3 deg C Contact Forece: Max 85kgf per Contactor |
 |
Test Site: Max 4 Site Test Pitch: 4site (40mm) 2site (80mm) UPH: Max 1,500 Temperature: -50 to 150 deg C Contact Forece: 80 kgf |
 |
Test Site: Single Site Test Pitch: Center Single UPH: Max 500 Temperature: -50 to 150 deg C Contact Forece: 30 kgf |
| Tri-Temp Model | |
|---|---|
 |
Test Site: Max 8 Site Test Pitch: 8 site (40x60mm) Temperature: -55 to 150 deg C Contact Forece: Max 85 kgf (150kgf/300kgf as option) |
|
Test Site: Max 8 Site Test Pitch: 8 site (40x60mm) Temperature: -55 to 150 deg C Contact Forece: Max 85 kgf (150kgf/300kgf as option) |
|
Test Site: 1 Site Test Pitch: Center Single Temperature: -55 to 150 deg C Contact Forece: Max 40 kgf |
